Mini Split unit

Mini Split PHI-Air Purification System

The Mini Split PHI System by RGF® is a PHI Cell® technology. The product is easily mounted onto a mini split AC unit without modification by using hook-and-loop adhesive strips. The Mini Split PHI incorporates its own pull out reusable copper/silver ionic germicidal electro static filter and installs into any 100-277 VAC 50/60 Hz power supply (typically at the input power to the mini split unit).

Note: It is recommended these units be installed by a licensed electrician or HVAC professional

Left right Aroow
Scroll
Model # Technology Recommended Cell Replacement Power Supply PDF
MINI SPLIT-HVAC-PHI-110 PHI-CELL® 18,000 – 25,000 hrs. 110 VAC

View PDF

MINI SPLIT-HVAC-PHI-230 PHI-CELL® 18,000 – 25,000 hrs. 230 VAC 50/60 Hz

View PDF

  • Features & Benefits
  • Technical Specs

• Kills bacteria, viruses and mold.
• Reduces odors and VOCs (Volatile Organic Compounds)
• Easy installation

Left right Aroow
Scroll
Model # Mini-Split-HVAC-PHI-110 Mini-Split-HVAC-PHI-230
Technology PHI-CELL® PHI-CELL®
Recommended Cell Replacement 18,000 – 25,000 hrs. 18,000 – 25,000 hrs.
Replacement Cell Part # PHIC-5MS-GA PHIC-5MS-GA
Power Supply 110 VAC 230 VAC 50/60 Hz
Amps 0.12 A 0.04 A
Watts 13.2 W 9 W
Tonnage 3/4 – 16.25 3/4 – 16.25
CFM’s 250 – 2,000 250 – 2,000
Installation External mount External mount
Material Aluminum / polymers Aluminum / polymers
Dimensions 30” W x 2.5” D x 1.25” H 30” W x 2.5” D x 1.25” H
Ship Weight 3 lbs. 3 lbs.
Warranty 2 Years (U.S. only) 2 Years (U.S. only)

Certifications & Awards

UL 1598:2008 (3rd Edition)
CAN/CSA C22.2 No.250.0:2008
EN 60335-2-65/A1:2008
