EA-HEPA

Element Air™ HEPA
Air Filtration System

Ducted HEPA Advantage
The Element Air™ HEPA ducted air filtration system is easily installed in your facility’s HVAC or air handling system to provide 99.97% airborne particulate reduction without impacting air flow, static pressure or unit sizing. This whisper-quiet air filtration system is efficient in removing particles >0.3 microns in size. It is recommended for areas up to 5,000 sq. ft.

Left right Aroow
Scroll
ITEM# ELECTRICAL DIMENSIONS WEIGHT LBS. PDF
EAM-350 120 VAC 50/60 HZ 2' 3" H x 1' 3" W x 1' 3" L 40

View PDF

EAM-675 120 VAC 50/60 HZ 2' 3" H x 1' 3" W x 1' 3" L 40

View PDF

  • Reduces
  • Applications
  • Features & Benefits
  • Technical Specs

•Odors
•VOCs
•Microbials
•Particulate

•Cultivation Rooms
•Large Harvest Rooms
•Green Houses
•Processing Rooms
•Offices
•Dry/Cure Rooms

• No negative impact on AC blower static pressure
• Insulated cabinets for whisper-quiet operation
• Low maintenance; HEPA cartridges can last up to five years
depending on the environment
• Energy efficient due to effective design and quality motors
• Our Microcon® filtration systems are constructed out of durable
steel and finished with baked on powder coat paint
• Environmentally friendly
• VOC Canister contains carbon with 1,705,000 m2 of adsorbent
surface area for capturing chemicals

Left right Aroow
Scroll
Dimensions: 14.5”W x 27.5”H
Motor/Fan: Designed for continuous operation
Run tested for 50,000+ hours
Item# HEPA 350 HEPA 675
Inlet: 8” Duct Collar 10” Duct Collar
Outlet: 6” Duct Collar 8” Duct Collar
Weight: 30 lbs. 33 lbs.
Air Flow: 350 C.F.M. 675 C.F.M.
Electrical: 120V, 1.0 amps, 125 Watts 120V, 1.8 amps, 225 Watts
