Package PHI Unit -Air Purification System

The magnetic-mount Package Unit by RGF® is a PHI-Cell® technology. This product is specifically designed for package systems, but it has been used in a wide variety of applications due to its versatile magnetic mount installation. Adjustable magnetic feet attach without fasteners to the blower unit itself making installation as trouble-free as possible. Perfect for all applications where ductwork is hard to get to or modification to existing or HVAC systems in rental units is not an option. This 24V model connects directly into the control box of the HVAC unit. Now available in 5”, 9”, and 14” cells which handle package products from 1.5 to 20 tons.

Note: We recommend these units be installed by a licensed electrician or HVAC professional.

Left right Aroow
Scroll
Item # HVAC Blower Size Tonnage Dimensions Ship Weight PDF
PHI-PKG5-24V 250* to 1,200 CFM Up to 3.5 ton 2.25"W x 10.5”L x 1.7"D 1 lb.

View PDF

PHI-PKG9-24V 1,200 to 3,000 CFM 3.5 to 7.5 ton 2.25"W x 13.5”L x 1.75”D 1 lb.

View PDF

PHI-PKG14-24V 3,000 to 8,000 CFM 7.5 to 20 ton 2.25"W x 18.5”L x 1.75”D 2 lb.

View PDF

  • Features & Benefits
  • Applications
  • Technical Specs

• Kills bacteria, viruses and mold
• Reduces odors and VOCs (chemical odors)
• Easy, no-tool installation

• Small package products
• Vertical stack units
• Roof tops
• Gas package products
• Rental units where modification to the HVAC system is not allowed
• Anywhere ductwork is inaccessible

Left right Aroow
Scroll
Item # PHI-PKG5-24V PHI-PKG9-24V PHI-PKG14-24V
HVAC Blower Size 250* to 1,200 CFM 1,200 to 3,000 CFM 3,000 to 8,000 CFM
Tonnage Up to 3.5 ton 3.5 to 7.5 ton 2.25:W x 13.5”L x 1.75”D
Dimensions 2.25″W x 10.5”L x 1.75”D 2.25″W x 13.5”L x 1.75”D 2.25″W x 18.5”L x 1.75”D
Ship Wt. 1 lb. 1 lb. 2 lb.
*Install unit in conjunction with an HVAC system utilizing a minimum air volume of 250 cfm.
Replacement Cell Part # PHIC-5PKG PHIC-9PKG PHIC-14PKG
Description Package PHI Cell 5” Package PHI Cell 9” Package PHI Cell 14”
Technology PHI-CELL®
Recommended Cell Replacement 18,000 – 25,000 hrs.
Volts 24 VAC
Amps 0.48 A
Watts 11 W
Tonnage Up to 20 tons
CFM’s 250 – 8,000
Installation Air handler cabinet / magnetic mount
Material Aluminum
Dimensions 2.25” W x 10.5” L x 1.75” D
Warranty 2 years ballast / 2 years cell (U.S. only)
Hydro-Peroxides <.02 PPM

Certifications & Awards

UL 1598:2008 (3rd Edition)
CAN/CSA C22.2 No.250.0:2008
EN 60335-2-65/A1:2008
